Rockwell Automation Publication 280E-PM001A-EN-P – August 2011 73
ArmorStart
®
EtherNet/IP
™
Communications & Control Programming Manual Appendix A
12 Value of the parameter pointed to by "Parameter 14 Prod Assy Word 1" (low byte)
13 Value of the parameter pointed to by "Parameter 14 Prod Assy Word 1" (high byte)
14 Value of the parameter pointed to by "Parameter 15 Prod Assy Word 2" (low byte)
15 Value of the parameter pointed to by "Parameter 15 Prod Assy Word 2" (high byte)
16 Value of the parameter pointed to by "Parameter 16 Prod Assy Word 3" (low byte)
17 Value of the parameter pointed to by "Parameter 16 Prod Assy Word 3" (high byte)
Produce Assembly – Instance 151 “Drive Status” – Bulletin 284E Starters
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Trip Status
This parameter provides trip
identification.
Parameter Number 4
Access Rule GET
Data Type WORD
Group Basic Status
Units —
Minimum Value 0
Maximum Value 65535
Default Value 0
Bit
Function
1514131211109876543210
——————————————— X Short Circuit
—————————————— X — Overload
————————————— X —— Phase Short
———————————— X ——— Ground Fault
——————————— X ———— Stall
—————————— X ————— Control Power
————————— X —————— I/O Fault
———————— X ——————— Over Temperature
——————— X ———————— Over Current
—————— X ————————— A3 Power Loss
————— X —————————— Internal Comm
———— X ——————————— DC Bus Fault
——— X ———————————— EEPROM
—— X ————————————— HW Fault
— X —————————————— Restart Retries
X ——————————————— Misc. Fault
Point to
parameter 4,
Trip Status
