Maintenance
Repair
124 MagneMotion
Rockwell Automation Publication MMI-UM037A-EN-P - April 2020
• Torque wrench with the following bits:
• 2.5 mm Hex.
Procedure
Figure 50: Remove Precision Locator Pallet from Magnet Assembly
1. Remove the puck with pallet from the MagneMover LITE transport system (see
Replace Pucks on page 78).
M4 x 20 mm Screw
(2X)
Magnet Assembly
Pallet
Center Plate
Protective Strip
Threaded Standoff
Ski
Glue Dot
Preload Spacer
M4 x 8 mm Screw
(2X)
(2X)
Spacer
(2X)
