24
Publication 1763-IN001C-EN-P - June 2015
Shock,
Nonoperating
50 g panel mounted (40 g DIN Rail mounted); 3 pulses each direction,
each axis
Terminal Screw
Torque
0.56 Nm (5.0 in-lb) rated
Certifications UL Listed Industrial Control Equipment for use in Class 1, Division 2, Hazardous
Locations, Groups A, B, C, D
C-UL Listed Industrial Control Equipment for use in Canada
CE marked for all applicable directives
RCM marked for all applicable acts
EAC certified for: Russian Customs Union TR CU 020/2011 EMC Technical Regulation,
Russian Customs Union TR CU 004/2011 LV Technical Regulation
ESD Immunity EN 61000-4-2
4 kV contact, 8 kV air, 4 kV indirect
Radiated RF
Immunity
EN 61000-4-3
10V/m, 26 to 1000 MHz (alternatively, 80 to 1000 MHz),
80% amplitude modulation, +900 MHz keyed carrier
Fast Transient
Immunity
EN 61000-4-4
2 kV, 5 kHz
communications cable such as EtherNet, RS-232, and RS-485: 1 kV, 5 kHz
Surge Transient
Immunity
EN 61000-4-5
Unshielded communications cable: 2 kV CM (common mode), 1 kV DM (differential
mode)
Shielded communications cable: 1 kV galvanic gun
I/O: 2 kV CM (common mode), 1 kV DM (differential mode)
ac Power Supply Input: 4 kV CM (common mode), 2 kV DM (differential mode)
dc Power Supply Input: 500V CM (common mode), 500V DM (differential mode)
ac/dc Auxiliary Output: 500V CM (common mode), 500V DM (differential mode)
Conducted RF
Immunity
EN 61000-4-6
10V, 150 kHz...80 MHz
General Specifications
Description 1763-
L16AWA L16BWA L16BBB L16DWD
