25
Publication 1763-IN001C-EN-P - June 2015
Input Specifications
Conducted
Emissions
EN 55011
ac Power Supply Input: 150 kHz...30 MHz
Radiated
Emissions
EN 55011
30...1000 MHz
Line Related Tests EN 61000-4-11
ac Power Supply Input:
voltage drop: -30% for 10 ms, -60% for 100 ms
voltage interrupt: at voltage greater than -95% for 5 secs.
voltage fluctuation: +10% for 15 minutes, -10% for 15 minutes
dc Power Supply Input:
voltage fluctuation: +20% for 15 minutes, -20% for 15 minutes
Digital Inputs
Description 1763-L16AWA 1763-L16BWA, -L16BBB
Inputs 0 through 3
(4 high-speed dc inputs)
Inputs 4 and higher
(6 standard dc inputs)
On-State Voltage
Range
79 ...132V ac 14...24V dc
(14...26.4V dc (+10%) at
65 °C/149 °F)
(14...30V dc (+25%) at
30 °C/86 °F)
10...24V dc
(10...26.4V dc (+10%) at
65 °C/149 °F)
(10...30V dc (+25%) at
30 °C/86 °F)
Off-State Voltage
Range
0...20V ac 0...5V dc
Operating
Frequency
47...63 Hz 0 Hz...20 kHz
0 Hz...40 kHz
(1)
0 Hz...1 kHz
(scan time dependent)
On-State Current:
• minimum
• nominal
• maximum
• 5.0 mA at 79V
ac
• 12 mA at 120V
ac
• 16.0 mA at
132V ac
• 2.5 mA at 14V dc
• 8.8 mA at 24V dc
• 12.0 mA at 30V dc
• 2.0 mA at 10V dc
• 8.5 mA at 24V dc
• 12.0 mA at 30V dc
General Specifications
Description 1763-
L16AWA L16BWA L16BBB L16DWD
