12 MicroLogix™ 1500 Programmable Controller Base Units
Publication 1764-IN001B-EN-P
To remove your base unit from the DIN rail:
1. Place a flat-blade screwdriver in the DIN rail latch at the bottom of the base
unit.
2. Holding the base unit, pry downward on the latch until the latch locks in the
open position. This releases the base unit from the DIN rail.
Using Mounting Screws
Mount to panel using #8 or M4 screws.
Mounting Template
