MicroLogix™ 1500 Programmable Controller Base Units 17
Publication 1764-IN001B-EN-P
Specifications
Table 9 General Specifications
Description 1764-24BWA 1764-24AWA 1764-28BXB
Number of I/O 12 inputs
12 outputs
12 inputs
12 outputs
16 inputs
12 outputs
Line Power 85/265V ac 85/265V ac 20.4 to 30V dc
Power Supply Inrush 120V ac = 25A
for 8 ms
240V ac = 40A
for 4 ms
120V ac = 25A
for 8 ms
240V ac = 40A
for 4 ms
24V dc = 4A
for 150 ms
User Power Output 24V dc at 400 mA,
400 µf max.
none none
Input Circuit Type 24V dc, sink/source 120V ac 24V dc, sink/source
Output Circuit Type relay relay 6 relay,
6 FET transistor
Operating Temp. +0°C to +55°C (+32°F to +131°F) ambient
Storage Temp. -40°C to +85°C (-40°F to +185°F) ambient
Operating Humidity 5% to 95% relative humidity (non-condensing)
Vibration Operating: 10 to 500 Hz, 5G, 0.015 in. peak-to-peak
Relay Operation: 2G
Shock (without Data
Access Tool installed)
Operating: 30G panel mounted (15G DIN Rail mounted)
Relay Operation: 7.5G panel mounted (5G DIN Rail mounted)
Non-Operating: 40G panel mounted (30G DIN Rail mounted)
Shock (with Data Access
Tool installed)
Operating: 20G panel mounted (15g DIN Rail mounted)
Relay Operation: 7.5G panel mounted (5G DIN Rail mounted)
Non-Operating: 30G panel mounted (20G DIN Rail mounted)
Agency Certification •UL 508
• C-UL under CSA C22.2 no. 142
• Class I, Div. 2, Groups A, B, C, D
(UL 1604, C-UL under CSA C22.2 no. 213)
• CE compliant for all applicable directives
Terminal Screw Torque 1.13 Nm (10 in-lb) rated; 1.3 Nm (12 in-lb) maximum
Power Supply Isolation 2596V dc 2596V dc 1697V dc
Relay Outputs Isolation 2596V dc 2596V dc 2596V dc
Transistor Output Isolation none none 1697V dc
Inputs Isolation 2145V dc 2145V dc 1697V dc
User 24V Isolation 848V dc none none
