MC16 Operating Manual 09.01.2020
Tab Local Commands
The tab is available when an Access Door is created and it enables to assign Local Command(s) to the
door. Local Command parameters and functions are listed within the description of Local Command objects.
Inputs
Input represents object dedicated to receiving electric signals from external device/system. The status of
input is monitored and when changed then action can be started by controller. Type of action depends on
the function assigned to particular input (e.g. door opening detection, T&A Mode selection, arming, etc.)
One or more functions can be assigned to single input. When multifunction input is applied then its triggering
may start multiple actions in the system. More information on multifunction lines is given in AN010
application note. In case of inputs with the same toggle functions within the same object it is possible to
apply AND/OR logic. Additionally, in order to trigger an input in the system it may be necessary to
authenticate user at selected Access Point (reader).
Area General
Text box Name – enables to name the input.
Text box LCD Message – enables to specify input’s name which will be used on display.
Parameter Keypad Shortcut – enables to select key which will correspond to the input when interactive
options are applied.
Text box Description – enables to enter custom description for the input.
Area Object
Parameter Name – enables selection of physical input.
Info box Device – specifies device with selected input.
Info box Label – specifies type of object.
Info box Comment – displays comment which was assigned to the input during low level configuration.
Info box Type – specifies type of input (e.g. NO).
Info box IP Address – specifies IP address of host device (controller).
Info box RS Address – specifies RS485 address of device with the input.
Area Additional Options
Parameter Activity Schedule – enables assignment of schedule to specify when input can be triggered. It
requires earlier defining of General Purpose Maintained type Schedule.
Parameter Authentication Point – specifies Access Point where user must authenticate before input is
triggered. Such authentication requirement is configured in the area Authentication and Authorisation
Options when input is assigned to particular object (e.g. Access Door).
Option Multifunction – when the option is enabled then it is possible to specify the maximal number
functions for assignment to the input.
Parameter Function Limit – specifies the maximal number of functions for assignment to the input.
Area Events
Option Register event when input is switched ON – when the option is enabled then input triggering will
generate an event in the system.
Parameter Input ON Event – enables to indicate what event is generated in the system when the input is
triggered. It could be default event [661] or any other administrator defined event.
Option Register event when input is switched OFF – when the option is enabled then input releasing will
generate an event in the system.
Parameter Input OFF Event – enables to indicate what event is generated in the system when the input is
released. It could be default event [662] or any other administrator defined event.
Input object can be further configured, mainly in regard of its function on the level of other objects e.g.
Access Door. Other parameters for such configuration are given below, while parameters specific for
particular function are explained in the description of such function in the table 5.
Area General
Parameter Input – enables to select Input object.
