Roger MC16 - Page 21

MC16 Operating Manual 09.01.2020
21/52
116
AC Lost Toggle
Toggle
Power Supply
As long as triggered then lack of AC power supply is reported to controller.
117
Delayed AC Lost Toggle
Toggle
Power Supply
As long as triggered then delayed lack of AC power supply is reported to
controller.
118
Low Battery Toggle
Toggle
Power Supply
As long as triggered then low battery charging level is reported to controller.
119
Battery Failure Toggle
Toggle
Power Supply
As long as triggered then battery failure is reported to controller.
120
Power Supply Overload Toggle
Toggle
Power Supply
As long as triggered then overload of power supply unit is reported to
controller.
121
Set Emergency Door Unlocked
Mode
Event
Access Door
When triggered then Access Door is switched to Emergency Unlocked Door
Mode. Emergency type mode has higher priority than normal type mode
which can be set with functions [124] - [127]. The function can be used in
emergency door opening by fire alarm system.
122
Set Emergency Door Locked
Mode
Event
Access Door
When triggered then Access Door is switched to Emergency Locked Door
Mode. Emergency type mode have higher priority than normal type mode
which can be set with functions [124] - [127].
123
Clear Emergency Door Mode
Event
Access Door
When triggered then Emergency Door Mode is cleared and Normal Door
Mode is restored.
124
Set Locked Door Mode
Event
Access Door
When triggered then Locked Door Mode at Access Door is set.
125
Set Unlocked Door Mode
Event
Access Door
When triggered then Unlocked Door Mode at Access Door is set.
126
Set Normal Door Mode
Event
Access Door
When triggered then Normal Door Mode at Access Door is set.
127
Set Conditional Unlocked Door
Mode
Event
Access Door
When triggered then Conditional Unlocked Door Mode at Access Door is set.
128
Generate Door Lock Pulse
Event
Access Door
When triggered then door is opened for the time specified by the parameter
Lock Pulse if it is in Normal Door Mode. Input with the function is used mainly
for connection of exit button.
129
Generate Extended Door Lock
Pulse
Event
Access Door
When triggered then door is opened for the time specified by the parameter
Lock Pulse Extended if it is in Normal Door Mode.
130
Door Contact Toggle
Toggle
Access Door
As long as triggered then door opening is reported to controller. Input with the
function is used for connection of door contact.
131
Access Door Bell
Event
Access Door
When triggered then bell is activated at Access Door and output with the
function [34] is triggered.
132
Disable Door Toggle
Toggle
Access Door
As long as triggered then Access Door is blocked.
