133
Tamper Toggle
Toggle
Main Board
As long as triggered then sabotage alarm (controller or terminal enclosure
tampering) is raised and can be signalled by outputs with functions [58] and
[59].
134
Clear Door Forced Alarm
Event
Access Door
When triggered then Forced Door Alarm is cancelled.
135
Clear Door Open Too Long Alarm
Event
Access Door
When triggered then Door Open Too Long Alarm is cancelled.
136
Set Alternately Normal/Unlocked
Door Mode
Event
Access Door
When triggered then Access door is switched between Normal and Unlocked
Door Modes.
137
Emergency Unlocked Door Mode
Toggle
Toggle
Access Door
As long as triggered then Access Door is switched to Emergency Unlocked
Door Mode. Emergency type mode has higher priority than normal type mode
which can be set with functions [124] - [127]. The function can be used in
emergency door opening by fire alarm system.
138
Emergency Locked Door Mode
Toggle
Toggle
Access Door
As long as triggered then Access Door is switched to Emergency Locked
Door Mode. Emergency type mode has higher priority than normal type mode
which can be set with functions [124] - [127].
145
Set Node ON with Multiple
Parametric Times
Event
Automation
Node
When triggered then Automation Node is switched on for the time specified
by function parameter Parametric Time with delay specified by node
parameter Default delay. Series of input triggerings are added and
consequently the Automation Node can be switched on for multiple
parametric times.
146
Set Node ON with Multiple Default
Times
Event
Automation
Node
When triggered then Automation Node is switched on for the time specified
by node parameter Default Time with delay specified by node parameter
Default delay. Series of input triggerings are added and consequently the
Automation Node can be switched on for multiple default times. Total Time
Limit can be defined for the function to limit the maximal series of multiple
default times.
147
Set Node OFF Toggle
Toggle
Automation
Node
As long as triggered then Automation Node remains switched off.
148
Set Check-in Flag ON
Event
Access Point
When triggered then Check-in flag and outputs with functions [240], [242] and
[243] are switched on. The function is available only for MC16-HRC
controllers.
149
Set Check-in Flag OFF
Event
Access Point
When triggered then Check-in flag and output with function [243] are
switched off while outputs with functions [241] and [242] are switched on. The
function is available only for MC16-HRC controllers.
150
Set Alternately Check-in Flag
Event
Access Point
When triggered then Check-in flag is switched to opposite state. Outputs with
functions [240], [241], [242] and [243] are switched accordingly. The function
