4
! - indicator is on
" - indicator is off
# - indicator pulses
!R - indicator is red
!G - indicator is green
!R/G - indicator is red or green
Acoustic signals
SYMBOL OF
SIGNAL
NAME OF SIGNAL MEANING
* * * * * * * * * *
RESTART 1. The signal appears after switching on the power supply.
2. After an exit from programming modes.
3. After internal Watch Dog circuit operation.
* * *
O.K. signal 1. The programming functions were performed correctly.
2. A valid identifier (code or card) was used.
* * Encourage signal 1. The controller stands by for the remaining part of the command.
Type 1 error signal 1. A programming error.
2. An invalid identifier (code or card).
3. An attempt to program an identifier, which already exists in the reader.
Type 2 error signal 1. An attempt to assign the same functions to the IN1 and IN2 inputs.
*
Identifier reading
signal
1. An identifier (card or code) entry.
Etc.
Memory error 1. Controller memory data damage – the EEPROM memory should be RESET to
the default settings and the reader should be reprogrammed.
Users
The controller can distinguish the following four types of users:
USER TYPE
ID
NUMBER
AUTHORIZATION
INSTALLER NONE
Authorization for an entry to the installer programming mode, it does not have an identification
number.
MASTER 0
Authorization for an entry to the user programming mode, opening the door and switching the reader
between the CLOSED/OPEN conditions. Its identification number is 000.
SWITCHER
Full
001..049
Users with ID = 001..049 have authorization for opening the door and switching the controller
between the ON/OFF mode.
SWITCHER
Limited
050..099
Users with ID = 050..099 have authorization only for switching the controller between the ON/OFF
conditions
NORMAL 100..999
Authorization only for opening the door. The users of this type have identification numbers from 100
to 999.
The controller identifies the users by identifiers (abbrev.
Ident.
). Each user has his/her own identification number (ID = 000…999).
Identifier can be a code or proximity card
. In case the
[Dual identification mode]
option is switched on, the controller requires the use
of both forms of identification, i.e. code and card in any sequence. The controller accepts codes consisting from 3 up to 6 digits and
cards (proximity transponders) based on the V4001/2 module of EM MICROELECTRONIC – MARIN Switzerland.
Transponder module specification:
• 64-bit ROM memory, pre-programmed by the manufacturer.
• Amplitude modulation ASK (MANCHESTER coded).
• Operating frequency 125 kHz.
• Transmission speed 2kB/sec.
•
Note: The term "identifier" or "Ident." means the operation of code entering, card reading or both operations in case the [Dual
identification mode] is activated.
Examples:
1. [MASTER Ident.] = [MASTER code][#][MASTER card] or
2. [MASTER Ident.] = [MASTER code][#] or
3. [MASTER Ident.] = [MASTER card]
In example no. 1. the AND option is on for the MASTER identification of the user.
The ON and OFF mode of controllers
When controller stay in OFF (red) mode a SWITCH output is not active, when controller is in ON (green) mode the SWITCH output is
activated. Generally the SWITCH output is dedicated for integration with alarm system but it can be used for other purposes e.g. to
control access to specialized equipment (e.g. copy machine, computer, lighting, heating etc.)
Switching between ON and OFF mode
The ON/OFF mode can be controlled in few different ways:
- locally by use of SWITCHER or MASTER identifiers,
