d. Attach bottom of the Left
Handrail Arm (3L) to the bracket on
the front of the Left Foot Pedal
Assembly (2) using 1x Axle Bolt
(37) and Aircraft Nut (27).
e. Repeat step “d” to install Right
Handle Rail Arm (3R) to the Right
Foot Pedal Assembly(2).
f. Tighten all 6 x 15mm Bolts (20)
fitted in step 3c (page 7).
g. Attach Water Bottle Stand (56)
using 2 x 12mm Philips Screw (55).
