Remote control commands
R&S
®
RTA4000
499User Manual 1335.7898.02 ─ 08
*RST: LONG
SEARch:TRIGger:PATTern:WIDTh[:WIDTh] <Width>
Sets the reference time of a steady pattern, the nominal value for comparisons.
Parameters:
<Width> Default unit: s
SEARch:TRIGger:PATTern:WIDTh:DELTa <DeltaTime>
Sets a range Δt to the reference pattern duration set with SEARch:TRIGger:
PATTern:WIDTh[:WIDTh], if SEARch:TRIGger:PATTern:WIDTh:RANGe is set to
WITHin or OUTSide.
Parameters:
<DeltaTime> Default unit: s
17.6.4.9
Window search configuration
SEARch:TRIGger:LEVel:WINDow:LOWer.........................................................................499
SEARch:TRIGger:LEVel:WINDow:UPPer......................................................................... 499
SEARch:TRIGger:WINDow:DELTa...................................................................................499
SEARch:TRIGger:WINDow:POLarity................................................................................499
SEARch:TRIGger:WINDow:RANGe.................................................................................500
SEARch:TRIGger:WINDow:TIMerange............................................................................ 500
SEARch:TRIGger:WINDow:WIDTh..................................................................................501
SEARch:TRIGger:LEVel:WINDow:LOWer <LowerLevel>
SEARch:TRIGger:LEVel:WINDow:UPPer <UpperLevel>
Set the lower and upper voltage limits for the window.
Parameters:
<UpperLevel> *RST: 0.4
SEARch:TRIGger:WINDow:DELTa <DeltaWidth>
Defines a range around the width value (see SEARch:TRIGger:WINDow:DELTa).
Parameters:
<DeltaWidth> *RST: 100e-6
SEARch:TRIGger:WINDow:POLarity <Polarity>
Indicates the polarity of the pulse to be searched for.
Parameters:
<Polarity> POSitive | NEGative | EITHer
*RST: EITH
Waveform analysis
