Jul. 2013 AC-40
Exploded View (Fig. A)
fig.bunkai-A-e.eps
View A3
View A2
View A1
Solder
2locations
(wound)
Solder
2locations
(wound)
*Theendofthewiremustnotextend
belowtheconnector.
Windthewiring(#5100033167)
aroundthepowerswitchandsolder.
Securethewiringinplaceusingaclamp.
2025mm
1
4
5
17
11
9
19
18
16
10
15
13
12
14
6
1
7
8
3
2
