Jul. 2013 AC-40

Exploded View (Fig. A) Parts List

No. Part Code Part Name Description Q’ty

1 22150756 JACK NUT 2 PLASTIC/BLK 4

2 5100011024 R-KNOB(SD000083) 08203-500(40A-KAC-60-B) 11

3 ******** VR NUT M9 attached to potentiometer 11

******** VR MASHER attached to potentiometer 11

4 02897801 SEESAW SWITCH SDDJE13200 94V-0 1

5 5100010457 DC PLUG SUPPORTER 1

6 5100033207 CHASSIS 1

7 5100036137 CUSHION SLIDE SW 3

8 5100036138 HIMELON SLIDE SW 3

5100032329 PANEL SHEET ASSY 1

* This unit includes the following parts.

9 ******** GT INPUT BOARD 1

10 ******** MIC INPUT BOARD 1

11 ******** PANEL BOARD 1

12 ******** JACK BOARD 1

13 5100033242 MAIN BOARD ASSY 1

14 5100011021 STANDOFF M3-L6-H20 (311-BG436) 2

15 5100035706 CUSHION CHASSIS TOP L 1

16 5100035707 CUSHION CHASSIS TOP C 1

17 5100035705 CUSHION CHASSIS TOP R 1

18 5100035709 HIMERON CHASSIS REAR S 2

19 5100035708 HIMERON CHASSIS REAR L 1
