Jul. 2013 AC-40
Parts List
fig.-part1-e.eps
Safety Precautions:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
Note: The parts marked # are new. (initial parts) The description “Q’ty” means a necessary number of the parts per one product.
Due to one or more of the following reasons,
parts with parts code ******** cannot be supplied as service parts.
• Part supplied only as a component in a complete assembly
• Copyright does not permit the part to be supplied
• Part is sold commercially
CASING
# 5100033223 CABINET ASSY 1
# 5100033222 NET BOARD ASSY 1
5100009860 STAND 08203-016 (#SD001169) 1
CHASSIS
# 5100033207 CHASSIS 1
KNOB, BUTTON
5100011024 R-KNOB(SD000083) 08203-500(40A-KAC-60-B) 11
SWITCH
02897801 SEESAW SWITCH SDDJE13200 94V-0 1
5100007726 SWITCH SS71010F-0102-6T-015-NP 1
5100007725 SWITCH SS71020F-0103-6T-025-NP-017 2
JACK, EXT TERMINAL
04452956 3.5MM JACK YKB21-5401N 1
05019512 3.5MM JACK HTJ-035-09ABT 1
13449146 6.5MM JACK YKB21-5012 (W/SW) 3
13449252 6.5MM JACK YKB21-5006 (STEREO W/SW) 1
5100014678 CANNON CONNECTOR CT/PJ-02-EP(610-09064-03-00) 1
03562412 DC JACK HEC3900-010110 1
SPEAKER, BUZZER
# 5100033274 SPEAKER W6504-041A 2
PWB ASSY
# 5100033242 MAIN BOARD ASSY 1
# 5100032329 PANEL SHEET ASSY 1
* This unit includes the following parts.
******** PANEL BOARD 1
******** GT INPUT BOARD 1
******** MIC INPUT BOARD 1
******** JACK BOARD 1
DIODE
03349978 LED(RED) L-34HDSL-FPB 1
POTENTIOMETER
# 5100033257 ROTARY POTENTIOMETER R0923NOCH1P104FD20B4 2
# 5100033256 ROTARY POTENTIOMETER R0923NOCV1B103FD20A1 9
5100007731 ROTARY POT(231-11041-03-00) R1131GOXH1B203TG0027 1
FUSE, FUSE HOLDER
5100005125 FUSE MRT3.15 F200 on Jack Board 1
# 5100005117 FUSE MRT80 F300 on Main Board 1
5100005118 FUSE MRT100(472-11032-03-00) F2 on Main Board 1
To Next Page
