Jul. 2013 AC-40

Exploded View (All) Parts List

No. Part Code Part Name Description Q’ty

1 5100033223 CABINET ASSY 1

* This unit includes the following parts.

2 5100006069 RUBBER FOOT(430-BG-435) D25XT18 40484-512(SD001005) 4

3 5100009863 STAND HOLDER(40E-1BG-435) 40484-518 (#SD001007) 2

4 5100009860 STAND 08203-016 (#SD001169) 1

10 5100023934 CATCH D17.5 4

5 5100033222 NET BOARD ASSY 1

* This unit includes the following parts.

******** ROLAND BADGE 1

******** NET BOARD 1

6 5100033274 SPEAKER W6504-041A 2

7 5100011383 HANDLE HOLDER 2

8 5100011382 HANDLE PLATE 750-11038-03-00 1

9 5100011381 HANDLE 716-11038-01-00 1

11 5100036989 NITTO ACETATE TAPE #5 BLACK W12MM -
