Jul. 2013 AC-40

Location of Controls Parts List

No. Part Code Part Name Description Q’ty

1 13449146 6.5MM JACK YKB21-5012 (W/SW) 3

22150756 JACK NUT 2 PLASTIC/BLK 3

2 5100011024 R-KNOB(SD000083) 08203-500(40A-KAC-60-B) 2

5100033257 ROTARY POTENTIOMETER R0923NOCH1P104FD20B4 2

* This unit includes the following parts.

******** VR NUT M9 2

******** VR MASHER 2

3 5100011024 R-KNOB(SD000083) 08203-500(40A-KAC-60-B) 9

5100033256 ROTARY POTENTIOMETER R0923NOCV1B103FD20A1 9

* This unit includes the following parts.

******** VR NUT M9 9

******** VR MASHER 9

4 5100007725 SWITCH SS71020F-0103-6T-025-NP-017 2

5 5100014678 CANNON CONNECTOR CT/PJ-02-EP(610-09064-03-00) 1

6 5100007726 SWITCH SS71010F-0102-6T-015-NP 1

7 03349978 LED(RED) L-34HDSL-FPB 1

5100004216 LED SPACER LEDH-7 1

8 02897801 SEESAW SWITCH SDDJE13200 94V-0 1

5100033167 WIRING W3 1

9 5100010457 DC PLUG SUPPORTER 1

10 03562412 DC JACK HEC3900-010110 1

5100009659 DC JACK HOLDER 350-AP011-DH(750-11041-01-00) 1

11 04452956 3.5MM JACK YKB21-5401N 1

12 5100007731 ROTARY POT(231-11041-03-00) R1131GOXH1B203TG0027 1

13 05019512 3.5MM JACK HTJ-035-09ABT 1

14 13449252 6.5MM JACK YKB21-5006 (STEREO W/SW) 1

22150756 JACK NUT 2 PLASTIC/BLK 1
