55
7 Supplement
7
7-1 MAINTENANCE CHECK LIST
7 Supplement
Date: . .
MECHANICAL PARTS
LUBRICATION
FUNCTION CHECK
CONSUMABLE PARTS
Model Serial No.
CM-500
CM-400
CM-300
Check Points Confirmation
Carriage Driving Part 1. Drive Gear Dirty/Crack
2. Backlash Looseness
Grit Driving Part 1. Drive Gear Cleaning
2. Backlash Looseness
3. Grit Roller Foreign substance
Bed/Guide Rail 1. Pinch Roller Rotation/Wear down
2. Cutter Protection Dirty/Scratch
(Replacement depend on the scratch.)
Carriage 1. Carriage Loosen
2. Cutter Holder Loosen
Cutter Pen 1. Bearing Rotation of the Bearing
Description Life Confirmation
PAD, CUTTER CM-500 On demand
PAD, CUTTER CM-400 On demand
PAD, CUTTER CM-300 On demand
Check Points Confirmation
Floil G-474C X DRIVE GEAR OK•Cleaning & Lubrication
Y DRIVE GEAR OK•Cleaning & Lubrication
Molycoeat EM-50L Top part of GUIDE RAIL OK•Cleaning & Lubrication
Check Points Confirmation
1. FIRMWARE Version
Upgrade FIRMWARE to the latest version.
2. Panel Key
3. Carriage & Grit Compensation
4. Cutting Test • Wavy lines.
• Distorted figure.
• Pen Bouncing
• Noise
• Pen Pressure
• Media Shifting
• Qality of corners.
5. Connection check with Customer's PC.
To Next Page
