60
MIDI Parameters
Tx
Select “On” if you want the selected part to transmit MIDI data.
Parameter Value
Tx O, On
Tx Ch
Allows you to assign a MIDI transmit channel to the selected part.
Parameter Value
Tx Ch 1–16
Tx Shift
This parameter allows you to transpose the note messages before
they are transmitted to an external MIDI instrument or computer. The
maximum possible transposition is four octaves up (+48) or down
(–48).
Each step represents a semi-tone.
Parameter Value
Tx Shift –48–0–+48
Tx Local
This is where you can disconnect the part from the internal sound
source (“O”)–or re-establish that connection (“On”).
Parameter Value
Tx Local O, On
Tx Event
The “TX Event” section provides a number of lters that allow you
to specify whether the messages in question should be transmitted
(On) or not (O).
Filter Value Explanation
Program Change O, On
Select “On” to transmit program change
and bank select (CC00, CC32) messages.
Pitch Bender O, On
Select “On” to transmit Pitch Bend
messages.
Modulation O, On
Select “On” to transmit Modulation
messages (CC01).
Volume O, On
Select “On” to transmit Volume messages
(CC07).
Panpot O, On
Select “On” to transmit Panpot messages
(CC10).
Expression O, On
Select “On” to transmit Expression mes-
sages (CC11).
Reverb O, On
Select “On” to transmit Reverb messages
(CC91).
Chorus O, On
Select “On” to transmit Chorus messages
(CC93).
All O, On
Select “On” to transmit all MIDI message
listed above.
Rx
Select “On” if you want the selected part to receive MIDI data.
Parameter Value
Rx O, On
Rx Ch
Allows you to assign a MIDI receive channel to the selected part.
Parameter Value
Rx Ch 1–16
Rx Shift
This parameter allows you to transpose the note messages received
from an external MIDI instrument or computer. The maximum
possible transposition is four octaves up (+48) or down (–48). Each
step represents a semi-tone.
Parameter Value
Rx Shift –48–0–+48
Rx Limit Low/Limit High
“Limit Low” and “Limit High” allow you to set the note range to be
received. If not all note messages received on a given MIDI channel
should be played by the selected E-A7 part, narrow down the range.
Parameter Value
Rx Limit Low C- –G9
Rx Limit High C- –G9
NOTE
The “Limit Low” value cannot be higher than the “Limit High”
value (and vice versa).
Rx Event
The “Rx Event” section provides a number of lters that allow you
to specify whether the messages in question should be received (On)
or not (O).
Filter Value Explanation
Program Change O, On
Select “On” to receive program change
and bank select (CC00, CC32) messages.
Pitch Bender O, On
Select “On” to receive Pitch Bend
messages.
Modulation O, On
Select “On” to receive Modulation mes-
sages (CC01).
Volume O, On
Select “On” to receive Volume messages
(CC07).
Panpot O, On
Select “On” to receive Panpot messages
(CC10).
Expression O, On
Select “On” to receive Expression mes-
sages (CC11).
Reverb O, On
Select “On” to receive Reverb messages
(CC91).
Chorus O, On
Select “On” to receive Chorus messages
(CC93).
Hold O, On
Select “On” to receive Hold messages
(CC64).
Sostenuto O, On
Select “On” to receive Sostenuto messag-
es (CC66).
Soft O, On
Select “On” to receive Soft messages
(CC67).
Caf (Channel
aftertouch)
O, On
Select “On” to receive Caf-Channel
aftertouch.
RPN O, On
Select “On” to receive Registered param-
eter number messages (CC100/101).
NRPN O, On
Select “On” to receive Non-registered
parameter number messages (CC98/99).
System Exclusive O, On
Select “On” to receive System Exclusive
messages.
CC16 O, On
General purpose controller that allows
you to inuence the “C1” parameter.
Select “On” to receive this message type.
All O, On
Select “On” to receive all MIDI message
listed above.
