Roland INTEGRA-7 SuperNATURAL

14
Sep. 2012 INTEGRA-7
Parts List
fig.-part1-e.eps
Safety Precautions:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
Note: The parts marked # are new. (initial parts) The description “Q’ty” means a necessary number of the parts per one product.
Due to one or more of the following reasons,
parts with parts code ******** cannot be supplied as service parts.
• Part supplied only as a component in a complete assembly
• Copyright does not permit the part to be supplied
• Part is sold commercially
CASING
# 5100029239 TOP COVER 1
# 5100028713 FRONT PANEL 1
# 5100029258 RACK ANGLE 2
# 5100029252 BOTTOM CHASSIS 1
CHASSIS
# 5100029253 FRONT HOLDER 1
# 5100029254 VR BOARD HOLDER 1
KNOB, BUTTON
04124267 J R-KNOB SF-ELA BLK/SLV 990-05045-10-08 1
04897912 ZE R-KNOB LF SLVG/BLK 1
22495565 F S-BUTTON MX BLK 1
04566445 KEYTOP ZE CURSOR KEY A 1
04566456 KEYTOP ZE CURSOR KEY B 1
02011412 Y S-KEYTOP SD1H BLK 3
02011423 Y S-KEYTOP SD2H BLK 2
02011467 Y S-KEYTOP SX2H BLK 4
SWITCH
# 5100029168 PUSH SWITCH SPEC121300 1
01340290 TACT SWITCH EVQ11A05R 15
JACK, EXT TERMINAL
13449252 6.5MM JACK YKB21-5006 (STEREO W/SW) 1
00120434 JACK YKB21-5262 9
01782656 JACK 6.5MM YKB21-5166 3
13429273 MIDI CONNECTOR YKF51-5046 (TRIPRET) 1
5100019749 RCA CONNECTOR LPR6521-1301FC 1
04459190 USB CONNECTOR A TYPE FEMALE YKF45-0033N 1
5100009531 USB CONNECTOR B TYPE FEMALE YKF45-0044N 1
# 5100029169 XLR CONNECTOR CT3-21M-02-EP 2
DISPLAY UNIT
5100021175 LCD CMF2P0844-E 1
POWER SUPPLY UNIT
5100025676 SWITCHING REGULATOR PRL904-30 LF 1
PWB ASSY
# 5100029291 MAIN BOARD ASSY 1
# 5100029295 SUB SHEET ASSY 1
* This unit includes the following parts.
******** SUB BOARD 1
******** PANEL BOARD 1
******** JACK BOARD 1
******** FRONT JACK BOARD 1
******** VR BOARD 1
******** SW BOARD 1
******** ENC BOARD 1
******** INLET BOARD 1
DIODE
01904112 LED(RED) SLR-342VCT32 N.P.Q RANK 1
02125167 LED SLI-343DCT32W 7
04458767 LED SLI-343YYT32 1
04890378 LED SLR-342MGT32 1
