3
Main window
There are two views for the main window.
Press the [EDIT/BROWSE] button (p. 4) in the header to switch between the views (screens).
EDIT screen (p. 5)
BROWSE screen (p. 8)
Patch Manager window
Press the [ ] button (p. 4) in the header to call up the Patch Manager window.
Patch Manager window (p. 10)
Screen Layout
