Roland JV-1010 User Manual

40
Trying Out Desktop Music
4
Connect the other end of the computer cable to the JV-1010’s
COMPUTER connector.
fig.1-25.e
Serial port (|O|O|)
Apple Macintosh
Optional computer cable
RSC-15APL
PC
Optional computer cable
RSC-15AT
JV-1010 rear panel
Modem Port or
Printer Port
Playing back sounds from
the JV-1010 requires that
the AC adaptor be plugged
in and connection of either
audio cables or
headphones. If these
connections have not yet
b
een made, please refer to
“Making the
Connections” (p. 18). If
the connections are
complete, please see
“Switching On the
Power” (p. 20).

Roland JV-1010 Specifications

General

Type	Synthesizer Module
Polyphony	28 voices
Multitimbral	16 parts
MIDI	In, Out, Thru
Effects	Reverb, Chorus, Delay
Expansion Slot	1 SR-JV80 series expansion board
Synthesis Type	PCM
Outputs	Stereo (L/Mono, R)
Sound Engine	JV-1080 Sound Engine
Presets	512
Headphones	1/4 inch stereo jack
Power Supply	DC 9V
Patches	640 patches (user: 128, preset: 512)
