Roland JV-1010

68
MIDI Implementation
Model: JV-1010 (64 Voice Synthesizer Module)
Version: 1.00
Date: Jan. 28 1999
1. Data Reception
■ Channel Voice Messages
● Note Off
status 2nd byte 3rd byte
8nH kkH vvH
9nH kkH 00H
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
kk=note number: 00H - 7FH (0 - 127)
vv=Note Off velocity: 00H - 7FH (0 - 127)
* Not received in Performance mode when the Receive Switch (PERFORM/PART) is OFF.
* Not received by the Rhythm Part (Part 10) when the Envelope Mode is NO-SUS.
● Note On
status 2nd byte 3rd byte
9nH kkH vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
kk=note number: 00H - 7FH (0 - 127)
vv=Note On velocity: 01H - 7FH (1 - 127)
* Not received in Performance mode when the Receive Switch (PERFORM/PART) is OFF.
● Polyphonic Aftertouch
status 2nd byte 3rd byte
AnH kkH vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
kk=note number: 00H - 7FH (0 - 127)
vv=Aftertouch: 00H - 7FH (0 - 127)
* This message is received if the Aftertouch Source (SYSTEM) is POLY or CH&POLY.
* Not received in Performance mode when the Receive Switch (PERFORM/PART) is OFF.
* Not received in GM mode.
● Control Change
* If the corresponding Controller number is selected for the Patch Control Source 2/3
(PATCH), the corresponding effect will occur.
* If a Controller number that corresponds to the System Control Source 1/2 (SYSTEM) is
selected, the specified effect will apply if Patch Control Source 2/3 (PATCH) is set to
SYS-CTRL1 or SYS-CTRL2.
* Not received in Performance mode when the Receive Switch (PERFORM/PART) or the
Control Change Receive Switch is OFF.
❍Bank Select (Controller number 0,32)
status 2nd byte 3rd byte
BnH 00H mmH
BnH 20H llH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
mm,ll=Bank number: 00 00H - 7F 7FH (bank.1 - bank.16384)
* Not received when the Receive Program Change or Receive Bank Select (SYSTEM) is
OFF.
* Not received in GM mode.
* The Patches corresponding to each Bank Select are as follows.
Bank Select | Program No | Group Patch No.
MSB | LSB | |
——————+—————+————————————+————————————————————————————————————————
80 | 0 | 0 - 127 | User 1 - 128
81 | 0 | 0 - 127 | PR-A 1 - 128
81 | 1 | 0 - 127 | PR-B 1 - 128
81 | 2 | 0 - 127 | PR-C 1 - 128
81 | 3 | 0 - 127 | GM 1 - 128
81 | 4 | 0 - 127 | PR-E 1 - 128
84 | 0 | 0 - 127 | XP-A (Session) 1 - 128
84 | 1 | 0 - 126 | XP-A 129 - 255
84 | 2 | 0 - 127 | XP-B 1 - 128
84 | 3 | 0 - 127 | XP-B 129 - 256
* The Performance corresponding to each Bank Select are as follows.
Bank Select | Program No | Group Performance No.
MSB | LSB | |
——————+—————+————————————+————————————————————————————————————————
80 | 0 | 0 - 31 | User 1 - 32
81 | 0 | 0 - 31 | PR-A 1 - 32
81 | 1 | 0 - 31 | PR-B 1 - 32
* The Rhythm set corresponding to each Bank Select are as follows.
Bank Select | Program No | Group Rhythm set No.
MSB | LSB | |
——————+—————+————————————+————————————————————————————————————————
80 | 0 | 0 - 1 | User 1 - 2
81 | 0 | 0 - 1 | PR-A 1 - 2
81 | 1 | 0 - 1 | PR-B 1 - 2
81 | 2 | 0 - 1 | PR-C 1 - 2
81 | 3 | 0 - 1 | GM 1 - 2
81 | 4 | 0 - 1 | PR-E 1 - 2
84 | 0 | 0 - 7 | XP-A (Session) 1 - 8
84 | 2 | 0 - 127 | XP-B 1 - 128
84 | 3 | 0 - 127 | XP-B 129 - 256
❍Modulation (Controller number 1)
status 2nd byte 3rd byte
BnH 01H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=Modulation depth: 00H - 7FH (0 - 127)
❍Breath type (Controller number 2)
status 2nd byte 3rd byte
BnH 02H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 7FH (0 - 127)
❍Foot type (Controller number 4)
status 2nd byte 3rd byte
BnH 04H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 7FH (0 - 127)
❍Portamento Time (Controller number 5)
status 2nd byte 3rd byte
BnH 05H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=Portamento Time: 00H - 7FH (0 - 127)
* Portamento Time will change.
❍Data Entry (Controller number 6, 38)
status 2nd byte 3rd byte
BnH 06H mmH
BnH 26H llH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
mm,ll= the value of the parameter specified by RPN/NRPN
mm=MSB, ll=LSB
❍Volume (Controller number 7)
status 2nd byte 3rd byte
BnH 07H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=Volume: 00H - 7FH (0 - 127)
❍Balance (Controller number 8)
status 2nd byte 3rd byte
BnH 08H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=Balance: 00H - 7FH (0 - 127)
