3-4 Replacing Consumable Parts
Chapter 3 Maintenance and Adjustment
61
Replacing the Blade
If the blade becomes dull, replace it with the included replacement blade.
CAUTION
Be sure to perform operations as specified by these instructions, and never touch
any area not specified in the instructions.
Sudden movement of the machine may cause injury.
CAUTION
Never touch the tip of the blade with your fingers.
Doing so may result in injury.
1.
Enter the blade replacement mode.
➊
Press .
Press
several times.
➋
Press .
Press
.
➌
Press .
Press
several times.
➍
Press .
The cutting carriage moves to a location where blade
replacement is possible, and then the screen shown in
the figure appears.
➎
Open the front cover.
Preparations are complete when this screen
appears.
2.
Replace the blade.
➊
Remove the blade holder.
MENU
SUB MENU
MAINTENANCE
REPLACE KNIFE
SUB MENU
MAINTENANCE
NOW PROCESSING..
FINISHED?
OPEN FRONT
COVER
To Next Page
