Roland XV-2020 - MIDI Implementation (cont.); 2. GS (Model ID = 42 H)

156
MIDI Implementation
| 00 78 | 0000 000a | WMT4 Wave Switch (0 — 1) |
| | | OFF, ON |
| 00 79 | 0000 00aa | WMT4 Wave Group Type (0 — 3) |
| | | INT, SR—JV80, SRX, SAMPLE<*> |
|# 00 7A | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | WMT4 Wave Group ID (0 — 16384) |
| | | OFF, 1 — 16384 |
|# 00 7E | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | WMT4 Wave Number L (Mono) (0 — 16384) |
| | | OFF, 1 — 16384 |
|# 01 02 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | WMT4 Wave Number R (0 — 16384) |
| | | OFF, 1 — 16384 |
| 01 06 | 0000 00aa | WMT4 Wave Gain (0 — 3) |
| | | —6, 0, +6, +12 [dB] |
| 01 07 | 0000 000a | WMT4 Wave FXM Switch (0 — 1) |
| | | OFF, ON |
| 01 08 | 0000 00aa | WMT4 Wave FXM Color (0 — 3) |
| | | 1 — 4 |
| 01 09 | 000a aaaa | WMT4 Wave FXM Depth (0 — 16) |
| 01 0A | 0000 000a | WMT4 Wave Tempo Sync (0 — 1) |
| | | OFF, ON |
| 01 0B | 0aaa aaaa | WMT4 Wave Coarse Tune (16 — 112) |
| | | —48 — +48 |
| 01 0C | 0aaa aaaa | WMT4 Wave Fine Tune (14 — 114) |
| | | —50 — +50 |
| 01 0D | 0aaa aaaa | WMT4 Wave Pan (0 — 127) |
| | | L64 — 63R |
| 01 0E | 0000 000a | WMT4 Wave Random Pan Switch (0 — 1) |
| | | OFF, ON |
| 01 0F | 0000 00aa | WMT4 Wave Alternate Pan Switch (0 — 2) |
| | | OFF, ON, REVERSE |
| 01 10 | 0aaa aaaa | WMT4 Wave Level (0 — 127) |
| 01 11 | 0aaa aaaa | WMT4 Velocity Range Lower (1 — 127) |
| | | 1 — UPPER |
| 01 12 | 0aaa aaaa | WMT4 Velocity Range Upper (1 — 127) |
| | | LOWER — 127 |
| 01 13 | 0aaa aaaa | WMT4 Velocity Fade Width Lower (0 — 127) |
| 01 14 | 0aaa aaaa | WMT4 Velocity Fade Width Upper (0 — 127) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 01 15 | 000a aaaa | Pitch Env Depth (52 — 76) |
| | | —12 — +12 |
| 01 16 | 0aaa aaaa | Pitch Env Velocity Sens (1 — 127) |
| | | —63 — +63 |
| 01 17 | 0aaa aaaa | Pitch Env Time 1 Velocity Sens (1 — 127) |
| | | —63 — +63 |
| 01 18 | 0aaa aaaa | Pitch Env Time 4 Velocity Sens (1 — 127) |
| | | —63 — +63 |
| 01 19 | 0aaa aaaa | Pitch Env Time 1 (0 — 127) |
| 01 1A | 0aaa aaaa | Pitch Env Time 2 (0 — 127) |
| 01 1B | 0aaa aaaa | Pitch Env Time 3 (0 — 127) |
| 01 1C | 0aaa aaaa | Pitch Env Time 4 (0 — 127) |
| 01 1D | 0aaa aaaa | Pitch Env Level 0 (1 — 127) |
| | | —63 — +63 |
| 01 1E | 0aaa aaaa | Pitch Env Level 1 (1 — 127) |
| | | —63 — +63 |
| 01 1F | 0aaa aaaa | Pitch Env Level 2 (1 — 127) |
| | | —63 — +63 |
| 01 20 | 0aaa aaaa | Pitch Env Level 3 (1 — 127) |
| | | —63 — +63 |
| 01 21 | 0aaa aaaa | Pitch Env Level 4 (1 — 127) |
| | | —63 — +63 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 01 22 | 0000 0aaa | TVF Filter Type (0 — 6) |
| | | OFF, LPF, BPF, HPF, PKG, LPF2, |
| | | LPF3 |
| 01 23 | 0aaa aaaa | TVF Cutoff Frequency (0 — 127) |
| 01 24 | 0000 0aaa | TVF Cutoff Velocity Curve (0 — 7) |
| | | FIXED, 1 — 7 |
| 01 25 | 0aaa aaaa | TVF Cutoff Velocity Sens (1 — 127) |
| | | —63 — +63 |
| 01 26 | 0aaa aaaa | TVF Resonance (0 — 127) |
| 01 27 | 0aaa aaaa | TVF Resonance Velocity Sens (1 — 127) |
| | | —63 — +63 |
| 01 28 | 0aaa aaaa | TVF Env Depth (1 — 127) |
| | | —63 — +63 |
| 01 29 | 0000 0aaa | TVF Env Velocity Curve Type (0 — 7) |
| | | FIXED, 1 — 7 |
| 01 2A | 0aaa aaaa | TVF Env Velocity Sens (1 — 127) |
| | | —63 — +63 |
| 01 2B | 0aaa aaaa | TVF Env Time 1 Velocity Sens (1 — 127) |
| | | —63 — +63 |
| 01 2C | 0aaa aaaa | TVF Env Time 4 Velocity Sens (1 — 127) |
| | | —63 — +63 |
| 01 2D | 0aaa aaaa | TVF Env Time 1 (0 — 127) |
| 01 2E | 0aaa aaaa | TVF Env Time 2 (0 — 127) |
| 01 2F | 0aaa aaaa | TVF Env Time 3 (0 — 127) |
| 01 30 | 0aaa aaaa | TVF Env Time 4 (0 — 127) |
| 01 31 | 0aaa aaaa | TVF Env Level 0 (0 — 127) |
| 01 32 | 0aaa aaaa | TVF Env Level 1 (0 — 127) |
| 01 33 | 0aaa aaaa | TVF Env Level 2 (0 — 127) |
| 01 34 | 0aaa aaaa | TVF Env Level 3 (0 — 127) |
| 01 35 | 0aaa aaaa | TVF Env Level 4 (0 — 127) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 01 36 | 0000 0aaa | TVA Level Velocity Curve (0 — 7) |
| | | FIXED, 1 — 7 |
| 01 37 | 0aaa aaaa | TVA Level Velocity Sens (1 — 127) |
| | | —63 — +63 |
| 01 38 | 0aaa aaaa | TVA Env Time 1 Velocity Sens (1 — 127) |
| | | —63 — +63 |
| 01 39 | 0aaa aaaa | TVA Env Time 4 Velocity Sens (1 — 127) |
| | | —63 — +63 |
| 01 3A | 0aaa aaaa | TVA Env Time 1 (0 — 127) |
| 01 3B | 0aaa aaaa | TVA Env Time 2 (0 — 127) |
| 01 3C | 0aaa aaaa | TVA Env Time 3 (0 — 127) |
| 01 3D | 0aaa aaaa | TVA Env Time 4 (0 — 127) |
| 01 3E | 0aaa aaaa | TVA Env Level 1 (0 — 127) |
| 01 3F | 0aaa aaaa | TVA Env Level 2 (0 — 127) |
| 01 40 | 0aaa aaaa | TVA Env Level 3 (0 — 127) |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 01 41 | Total Size |
+——————————————————————————————————————————————————————————————————————————————+
2. GS (Model ID = 42H)
❍System Parameter
+——————————————————————————————————————————————————————————————————————————————+
| Start | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
|# 40 00 00 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Master Tune (24 — 2024) |
| | | —100.0 — 100.0 [cent] |
| 40 00 04 | 0aaa aaaa | Master Volume (0 — 127) |
| 40 00 05 | 0aaa aaaa | Master Key Shift (40 — 88) |
| | | —24 — +24 [semitone] |
| 40 00 06 | 0aaa aaaa | Master Pan (1 — 127) |
| | | L63 — 63R |
|—————————————+————————————————————————————————————————————————————————————————|
| 40 00 7F | 0aaa aaaa | Mode Set (0, 127) |
| | | GS—RESET, GS—EXIT |
|—————————————+————————————————————————————————————————————————————————————————|
❍Common Parameter
+——————————————————————————————————————————————————————————————————————————————+
| Start | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 40 01 10 | 0aaa aaaa | Voice Reserve 1 (0 — 24) |
| 40 01 11 | 0aaa aaaa | Voice Reserve 2 (0 — 24) |
| 40 01 12 | 0aaa aaaa | Voice Reserve 3 (0 — 24) |
| 40 01 13 | 0aaa aaaa | Voice Reserve 4 (0 — 24) |
| 40 01 14 | 0aaa aaaa | Voice Reserve 5 (0 — 24) |
| 40 01 15 | 0aaa aaaa | Voice Reserve 6 (0 — 24) |
| 40 01 16 | 0aaa aaaa | Voice Reserve 7 (0 — 24) |
| 40 01 17 | 0aaa aaaa | Voice Reserve 8 (0 — 24) |
| 40 01 18 | 0aaa aaaa | Voice Reserve 9 (0 — 24) |
| 40 01 19 | 0aaa aaaa | Voice Reserve 10 (0 — 24) |
| 40 01 1A | 0aaa aaaa | Voice Reserve 11 (0 — 24) |
| 40 01 1B | 0aaa aaaa | Voice Reserve 12 (0 — 24) |
| 40 01 1C | 0aaa aaaa | Voice Reserve 13 (0 — 24) |
| 40 01 1D | 0aaa aaaa | Voice Reserve 14 (0 — 24) |
| 40 01 1E | 0aaa aaaa | Voice Reserve 15 (0 — 24) |
| 40 01 1F | 0aaa aaaa | Voice Reserve 16 (0 — 24) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 40 01 30 | 0aaa aaaa | Reverb Macro (0 — 7) |
| 40 01 31 | 0aaa aaaa | Reverb Character (0 — 7) |
| 40 01 32 | 0aaa aaaa | Reverb Pre—LPF (0 — 7) |
| 40 01 33 | 0aaa aaaa | Reverb Level (0 — 127) |
| 40 01 34 | 0aaa aaaa | Reverb Time (0 — 127) |
| 40 01 35 | 0aaa aaaa | Reverb Delay Feedback (0 — 127) |
| 40 01 36 | 0aaa aaaa | Reverb Send Level to Chorus<*> (0 — 127) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 40 01 38 | 0aaa aaaa | Chorus Macro (0 — 7) |
| 40 01 39 | 0aaa aaaa | Chorus Pre—LPF (0 — 7) |
| 40 01 3A | 0aaa aaaa | Chorus Level (0 — 127) |
| 40 01 3B | 0aaa aaaa | Chorus Feedback (0 — 127) |
| 40 01 3C | 0aaa aaaa | Chorus Delay (0 — 127) |
| 40 01 3D | 0aaa aaaa | Chorus Rate (0 — 127) |
| 40 01 3E | 0aaa aaaa | Chorus Depth (0 — 127) |
| 40 01 3F | 0aaa aaaa | Chorus Send Level to Reverb (0 — 127) |
|—————————————+————————————————————————————————————————————————————————————————|
❍Part Parameter
+——————————————————————————————————————————————————————————————————————————————+
| Start | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
|# 40 1x 00 | 0aaa aaaa | Tone Number CC#00 Value (0 — 127) |
| | 0aaa aaaa | Tone Number PC Value (0 — 127) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 40 1x 02 | 0aaa aaaa | Rx. Channel (0 — 16) |
| | | 1 — 16, OFF |
| 40 1x 03 | 0000 000a | Rx. Pitch Bend (0 — 1) |
| | | OFF, ON |
| 40 1x 04 | 0000 000a | Rx. Channel Pressure (0 — 1) |
| | | OFF, ON |
| 40 1x 05 | 0000 000a | Rx. Program Change (0 — 1) |
| | | OFF, ON |
| 40 1x 06 | 0000 000a | Rx. Control Change (0 — 1) |
| | | OFF, ON |
| 40 1x 07 | 0000 000a | Rx. Poly Pressure (0 — 1) |
| | | OFF, ON |
| 40 1x 08 | 0000 000a | Rx. Note Message (0 — 1) |
| | | OFF, ON |
| 40 1x 09 | 0000 000a | Rx. RPN (0 — 1) |
| | | OFF, ON |
| 40 1x 0A | 0000 000a | Rx. NRPN (0 — 1) |
| | | OFF, ON |
| 40 1x 0B | 0000 000a | Rx. Modulation (0 — 1) |
| | | OFF, ON |
| 40 1x 0C | 0000 000a | Rx. Volume (0 — 1) |
| | | OFF, ON |
| 40 1x 0D | 0000 000a | Rx. Panpot (0 — 1) |
| | | OFF, ON |
| 40 1x 0E | 0000 000a | Rx. Expression (0 — 1) |
| | | OFF, ON |
| 40 1x 0F | 0000 000a | Rx. Hold—1 (0 — 1) |
| | | OFF, ON |
| 40 1x 10 | 0000 000a | Rx. Portamento (0 — 1) |
| | | OFF, ON |
| 40 1x 11 | 0000 000a | Rx. Sostenuto (0 — 1) |
| | | OFF, ON |
| 40 1x 12 | 0000 000a | Rx. Soft (0 — 1) |
| | | OFF, ON |
|—————————————+———————————+————————————————————————————————————————————————————|
| 40 1x 13 | 0aaa aaaa | Mono / Poly Mode (0 — 1) |
| | | MODE, POLY |
| 40 1x 14 | 0aaa aaaa | Assign Mode<*> (0 — 2) |
| | | SINGLE, LIMITED—MULTI, |
| | | FULL—MULTI |
| 40 1x 15 | 0aaa aaaa | Use for Rhythm Part (0 — 2) |
| | | OFF, MAP1, MAP2 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 40 1x 16 | 0aaa aaaa | Pitch Key Shift (40 — 88) |
| | | —24 — +24 [semitone] |
|# 40 1x 17 | 0000 aaaa | |
| | 0000 bbbb | Pitch Offset Fine (8 — 248) |
| | | —12.0 — +12.0 [Hz] |
| 40 1x 19 | 0aaa aaaa | Part Level (CC# 7) (0 — 127) |
| 40 1x 1A | 0aaa aaaa | Velocity Sens Depth (0 — 127) |
| | | —64 — +63 |
| 40 1x 1B | 0aaa aaaa | Velocity Sens Offset (0 — 127) |
| | | —64 — +63 |
| 40 1x 1C | 0aaa aaaa | Part Panpot (CC# 10) (0 — 127) |
| | | RANDOM, L63 — 63R |
| 40 1x 1D | 0aaa aaaa | Keyboard Range Low (0 — 127) |
| 40 1x 1E | 0aaa aaaa | Keyboard Range High (0 — 127) |
| 40 1x 1F | 0aaa aaaa | CC1 Controller Number (0 — 95) |
| 40 1x 20 | 0aaa aaaa | CC2 Controller Number (0 — 95) |
| 40 1x 21 | 0aaa aaaa | Chorus Send Level (CC# 93) (0 — 127) |
| 40 1x 22 | 0aaa aaaa | Reverb Send Level (CC# 93) (0 — 127) |
