3 | Automate™ Programming Instructions | ARC™ Venetian Tilt Motor ROLLEASE ACMEDA
CONTENTS
1 ASSEMBLY 5
2 WIRING 6
2.1 Power Options 6
3 P1 BUTTON FUNCTIONS 7
3.1 Motor State Test 7
3.2 Motor Configuration Options 7
4 INTIAL SETUP 8
4.1 Pair Motor with controller 8
4.2 Check motor direction 8
4.3 Set limits 9
5 ADJUSTING LIMITS 10
5.1 Adjust upper limit 10
5.2 Adjust lower limit 10
6 ADDING OR REMOVING CONTROLLERS AND CHANNELS 11
6.1 Using motor P1 button 11
6.2 Using a pre-existing controller 11
7 FAVORITE POSITIONING 12
7.1 Set favorite position 12
7.2 Send shade to favorite position 12
7.3 Delete favorite position 12
8 SLEEP MODE 13
8.1 Enter sleep mode 13
8.2 Exit sleep mode 13
9 TROUBLESHOOTING 14
