Romer DUO plus - Page 4

GB
4
 The hook* 4 must be open on both
connectors 3. To open the hook squeeze
the locking button 5 and the red release
button 6 together (refer to 2. Engage
ISOFIX).
3
4
3
4
 Position the two connectors 3 directly in
front of the two insertion guides 1.
1
3
3
1
2. Engage ISOFIX
 Press the locking button 5 on one side to
the back and engage the connector 3
("click").
3
5
6
5
3
 Press the locking button 5 on the other
side to the back and engage the
connector 3 ("click").
5
3
part number: 09163186 ( GM ) / 93181287 ( Vauxhall )
