GB
5
To release the locking mechanism turn the
green lever 34 downwards.
Then push the child seat with the lever 34
turned down towards the backrest.
34
Push the child seat towards the backrest
applying firm, even pressure on both
sides.
Pull both sides to check that the seat is
positioned firmly.
Checklist for correct installation
For the safety of your child, check that…
• the child seat is firmly installed in the vehicle.
• the seat shell with the connectors is engaged in the ISOFIX fastening on both
sides.
Removal
To release the ISOFIX fastening, squeeze the locking button 5 and the red
release button 6 together, first on one side, then on the other. The connectors
3 are disengaged.
part number: 09163186 ( GM ) / 93181287 ( Vauxhall )
