Output O1: Connection of the 12V DC (acoustic and / or optical).
Output O1: connection of 12V DC load.
- O2-O4 in the active state can supply (NO) or disconnect (NC) 0V power supply (GND).
(open collector transistor output OC, control "supply ground", 700mA max.)
O2-O4 output: connection of 12VDC / 700mA siren max. (acoustic and / or optical).
