System configuration
© 2017 Ropam Elektronik
log
indicator of signing modem to the GSM network,
assumes a binary value 0 or 1
0 = not connected to GSM network
1 = modem connected to GSM network
jmg
GSM jamming indicator, takes a binary value 0 or
1
0 = no GSM jamming
1 = GSM jamming
as
Full system standby, takes a binary value 0 or 1,
0 = no full standby(supervision)
1 = full standby (supervision)
al
alarm rate in the system, takes a binary value0 or
1,
0 = no alarm
1 = alarm status
sec
operating time unit [s] from the time of restarting,
accuracy 1%
sec= xx
uzv
supply voltage value DC [mV]
xxxx (eg: 13800[mV])
nlv
GSM network level 1-4, called. 'dashes'
1÷4
fcd
failure code xx (see SMS STAN)
00 = no failure
xx = failure
0
Binary Value 0, object type Binary Value
0 - description of result in table "Logical
function"
1
Binary Value 1, object type Binary Value
1 - description of result in table "Logical
function"
Logical function (If)
Symbol
Description
Name
==
returns true, if both arguments are the same value.
equality
!=
returns true if both arguments have different values
inequality
_|
returns true if the argument has a rising edge
equality; rising edge
--|
returns true if the argument has a falling edge
equality; falling edge
>
returns true if the left argument has a bigger value than
the right
bigger than
<
returns true if the left argument has a smaller value
than the right
smaller than
>=
returns true if the left argument is bigger or equal to the
right value
bigger or equal
<=
returns true if the left argument is smaller than or equal
to the right value
smaller or equal
Result (Output)
Symbol
Description
Logical values
O1÷O4
physical output state, takes a binary value 0 or
1, object type Binary Output
0 = inactive output
1 = active output
M1÷M16
markers value, takes a binary value 0 or 1,
object type Binary Value
0 = marker value 0
1 = marker value 1
