Rosemount 8732 Series User Manual

Quick Installation Guide
00825-0100-4725, Rev BA
July 2003
Rosemount 8732/8700 Series
Table 2. Flange Bolt Torque and Bolt Load Specifications for 8705
Teflon/Tefzel liner
Size
Code
PN10 PN 16 PN 25 PN 40
Line Size
(Newton-
meter)
(Newton)
(Newton-
meter)
(Newton)
(Newton-
meter)
(Newton)
(Newton-
meter)
(Newton)
005 0.5-inch
(15 mm)
10 4400 10 4400
010 1 inch
(25 mm)
20 10100 20 10100
015 1.5 inch
(40 mm)
50 16100 50 16100
020 2 inch
(50 mm)
60 20100 60 20100
030 3 inch
(80 mm)
50 16800 50 16800
040 4 inch
(100 mm)
50 17800 70 19600
060 6 inch
(150mm)
90 24700 130 28700
080 8 inch
(200 mm)
130 35200 90 19700 130 29200 170 34400
100 10 inch
(250 mm)
100 28000 130 28300 190 38000 250 44800
120 12 inch
(300 mm)
120 32000 170 38400 190 38600 270 47700
140 14 inch
(350 mm)
160 43800 220 49500 320 57200 410 68100
160 16 inch
(400 mm)
220 50600 280 56200 410 68100 610 92900
180 18 inch
(450 mm)
190 43200 340 68400 330 55100 420 64000
200 20 inch
(500 mm)
230 51100 380 68900 440 73300 520 73900
240 24 inch
(600 mm)
290 58600 570 93600 590 90100 850 112000
4725_revBA_qig.fm Page 12 Thursday, July 3, 2003 12:47 PM

Rosemount 8732 Series Specifications

General

Category	Measuring Instruments
Diagnostics	Yes
Measurement Type	Volumetric Flow
Output	4-20 mA, HART
Enclosure Rating	NEMA 4X, IP66
Communication Protocol	HART, FOUNDATION Fieldbus, Modbus
Product Type	Transmitter
Enclosure	Stainless Steel
Process Connection	Flanged
Material	Stainless Steel
Certifications	ATEX, IECEx, CSA, FM
Power Supply	11 to 42.4 VDC
Flow Range	0.04 to 12 m/s (0.13 to 39 ft/s)
