38 • Configuration ULTRIX-MODX-IO User Guide (v1.0)
 Filter the table by using the Views and Options menus in the top toolbar of the page.
Table 3 summarizes the columns that display when Views is set to Ports for an ULTRIX-MODX-IO
blade populated with at least one ULTRIX-MOD-SFP.
Table 3 Port Configuration — Views > Ports
Item Parameters Description
Group # Indicates the physical slot the module/port is
located where Group 1 is the first slot in the blade.
Physical Address Slot.Port.Type.Channel Lists the physical ports, in ascending order, of the
ULTRIX-MODX-IO. Each row represents a port.
Video # If a port is used for video signals, this field indicates
the type of video (e.g. HD, 3G, UHD, etc.).
Audio # If a port is used for audio signals, this field indicates
the type of audio detected (e.g. PCM, AES etc.).
Timing Lines
(read-only)
# Reports the value of timing difference between
input and frame reference in number of lines.
Detecting The timing difference is being detected; updates the
field approximately every 33 seconds.
Async There is no timing relationship between the input
signal and the frame reference.
Timing Pixels
(read-only)
# Reports the value of timing difference between
input and frame reference in number of pixels.
Detecting The timing difference is being detected; updates the
field approximately every 33 seconds.
Async There is no timing relationship between the input
signal and the frame reference
Frame Sync
Delay
# frame(s) Specifies the frame buffer size for the selected input
port
LoS State
a
Black Sets the input to black during the loss of signal
Freeze Sets the input to the last valid frame of video before
the loss of signal
2-SI Group Enable Gearbox is available on the indicated I/O Group in
groups of 4 consecutive I/O. For example, selecting
Enable in the row for slot1.in[1] creates a Gearbox
group from slot1.in[1] to slot1.in[4].
Note that I/O Groups for Gearbox are defined in the
table using colored backgrounds.
Disable The indicated I/O is not included in a Gearbox
configuration
Signal Medic
(read-only)
b
Not available This port does not support the Gearbox feature.
Good This port is included in a Gearbox setup.
Replaced This port can be included in a Gearbox setup but is
currently not included in the 12G link.
