• The Lock Strike will remain active
according to the programmed Release
Time.
• In addition, it is possible to activate the
Lock Strike in the following ways:
a. Pressing the REX button
b. Valid Code (from an outside reader
only using Prox. Code or Pin. Code)
2) Bypass Mode
• The DOOR 1 /
DOOR 2 LED is
orange
DOOR 1
DOOR 2
ORANGE
• In this mode the Controller is in the
lowest level of security.
• The Controller’s keypad is used for
changing modes of operation and
activating the Lock Strike by the
employee codes or by pressing the “*/#”
key accordingly.
• The Lock Strike will remain active
according to the programmed Release
Time.
• If the Lock Strike is defined as Normally
Closed it will always be active. If the
Lock Strike is defined as Normally Open
it can be activated in the following ways:
a. Pressing the REX button
AC-020 Page 23 03/02
b. Valid Code (from an outside reader
only using Prox. Code or Pin. Code)
To Next Page
