Rosslare AC-225-B Series User Manual

Technical Specifications
12 AC-225x-B Series Hardware Installation and User Manual
Environmental Characteristics
Operating Temperature Range
0°C to 49°C (32°F to 120°F)
Operating Humidity Range
0 to 85% (non-condensing)
Dimensions
Height x Width x Depth
193 x 136.5 x 39 mm (7.6 x 5.4 x 1.5 in.)
Weight
0.36 kg (12.7 oz)
2.2 AC-225x-B Installed in ME-1015
Electrical Characteristics – Switch Mode Power Supply
Operating Voltage
90 ~ 240 VAC, 50 ~ 60 Hz from mains power
Maximum Input Current
1.5 A
Output Power
15 VDC, 4 A (60 Watts) to the power
management board
Electrical Characteristics – Power Management Board (PM-10)
Input Power
15 VDC, 4 A to the power management board
Output Power
Two PTC fused outputs
Each provides 13.8 VDC, 1.5 A (battery only: 8.8-
11.8 VDC)
One output for controller and readers
One output for locks
Battery Charger
13.8 VDC, 300 mA for 12 VDC, 7 Ah Lead Acid
Battery
Speaker
0.5 Watt, 8 Ohm
Light Bar
0.3 Watt for LED light
Environmental Characteristics
Operating Temperature Range
0°C to 49°C (32°F to 120°F)
Operating Humidity Range
0 to 85% (non-condensing)
Dimensions
Height x Width x Depth
364 x 264 x 87.4 mm (14.3 x 10.4 x 3.4 in.)
Weight
3.4 kg (7.5 lb)

Rosslare AC-225-B Series Specifications

General

Brand	Rosslare
Model	AC-225-B Series
Category	Control Panel
Language	English
