AC-225x-B Hardware Settings

30 AC-225x-B Series Hardware Installation and User Manual

Reader4

(Door2 OUT/IN)

Four Door with 4 Readers (MD-D02B)

Outputs

Door1 Lock output

(OUT 1)

General purpose output

(OUT 1A)

Door2 Lock output

(OUT 2)

General purpose output

(OUT 2A)

Door3 Lock output

(OUT 5)

General purpose output

(OUT 6)

Door4 Lock output

(OUT 7)

General purpose output

(OUT 8)

Inputs

Door1 Request to exit

(IN 1)

Door1 monitor input

(IN 1A)

Door2 Request to exit

(IN 2)

Door2 monitor input

(IN 2A)

Door3 Request to exit

(IN 5)

Door3 monitor input

(IN 6)

Door4 Request to exit

(IN 7)

Door4 monitor input

(IN 8)

Readers

Reader1

(Door1 IN/OUT)

Reader2

(Door2 IN/OUT)

Reader3

(Door3 IN/OUT)

Reader4

(Door4 IN/OUT)

5.4 Access Control Panel Addressing

The last five DIP switches are used to set the binary code of the access control

panel internal network address. The default access control panel address is “1”.

For successful communications, the DIP switch must match the address set in the

AxTraxNG software.

Table 6 displays the 32 address settings available:

Table 6: Available Panel Addresses

Address

Switch 4

Switch 5

Switch 6

Switch 7

Switch 8

OFF
