Introduction
AC-225x-B Series Hardware Installation and User Manual 9
battery of up 12 V and 7 Ah, and an intelligent light bar that provides enclosure
lighting, an enclosure tamper sensor, and a power status LED indicator.
Figure 1 shows the general layout of the AC-225x-B panel.
Figure 1: AC-225x-B Panel Layout
1.1 AxTraxNG
The AxTraxNG software system is designed to set up, manage, and supervise all
aspects of an access control panel network.
Table 2 presents the AxTraxNG software capabilities:
Table 2: AxTraxNG Capabilities
Users capacity
30,000
Unauthorized Users
30,000
Access groups
30,000
Number of panels in system
1,023
Number of doors in system
4,092
These options are software and firmware dependent, and may change in later
releases or revisions.
