Rosslare AC-225-B Series User Manual

Introduction
8 AC-225x-B Series Hardware Installation and User Manual
1. Introduction
In this manual, unless otherwise stated, “AC-225x-B” refers to both the regular AC-
225-B and the AC-225IP-B moels
The AC-225x-B series of access control panels are state-of-the-art networked
access controllers, employing the latest technology to meet the requirements of
the market.
Table 1 summarizes the series of AC-225x-B models and their respective
descriptions.
Table 1: Description of AC-225x-B Panels
Model Name
Description
AC-225-BA
Installed in ME-1015 with Type I plug power cable
AC-225-BB
Installed in ME-1015 with Type G plug power cable
AC-225-BE
Installed in ME-1015 with Type F plug power cable
AC-225-BU (#)
Installed in ME-1015 with Type B plug power cable
AC-225-DIN (#)
PCBA only with wall / DIN rail mounting base
AC-225IP-BA
Installed in ME-1015 with Type I plug power cable
AC-225IP-BB
Installed in ME-1015 with Type G plug power cable
AC-225IP-BE
Installed in ME-1015 with Type F plug power cable
AC-225IP-BU (#)
Installed in ME-1015 with Type B plug power cable
AC-225IP-DIN (#)
PCBA only with wall / DIN rail mounting base
The IP models also includes onboard support for communications across a TCP/IP
network.
(#) UL Certified.
When used in combination with Rosslare's AxTraxNG™ software system, the AC-
225x-B gives you full control over access to your premises. The system can control
both single and double door entrances and up to four doors, with MD-D02B 2-door
expansion module. AC-225x-B supports up to 30,000 users and uses flash memory
to enable easy firmware upgrades. For more information on the AxTraxNG system,
refer to the AxTraxNG™ Software Installation and User Manual.
The AC-225x-B comes either as a PCBA “DIN” module that can be wall or DIN rail
mountable, or pre-assembled within the ME-1015 power management enclosure.
The ME-1015 contains a universal switch mode power supply that accepts inputs
from 90 ~ 240 VAC (50 ~ 60 Hz) and outputs 60 watts, a power management board
that provides two independently fused 12 VDC, 2 Amp power outputs – one for
the controller and readers, and one for locks. The ME-1015 power management
enclosure also includes an alert sounder, a lead acid battery charger for a lead acid
