AC-225x-B Panel Setup
AC-225x-B Series Hardware Installation and User Manual 13
3. AC-225x-B Panel Setup
Each AC-225x-B panel controls one or two doors (up to 4 doors with MD-D02B).
The panels connect together in a network and are controlled by a central server
computer, running the AxTraxNG software system.
Figure 2 shows an example setup for a network of AC-225x-B access control panels.
Figure 2: AC-225x-B Sample Configuration
The use of bushings is required for any conductors leaving the enclosure through
the provided openings.
