Controller Operation
30 AYC-Ex5/T65 Series Installation and Programming Manual
4. Controller Operation
The AYC-Ex5/T65 can function both as a reader and as a controller.
If the unit is connected to Rosslare’s secured intelligent power
supply, it functions as a controller indicated by two beeps
immediately after power-on reset.
The Lock Strike and Auxiliary outputs, as well as the REX input, are
not located on the unit, eliminating the possibility of unauthorized
entry to the restricted area.
The use of a proximity card is not relevant for the AYC-E55
model.
4.1 Normal, Secure, and Master Users
The units accept up to 500 users and provide entry via the use of
PIN codes and/or proximity cards. Each user is provided with two
code memory slots, Memory Slot 1 (Primary code) and Memory
Slot 2 (Secondary code).
The PIN code length has several options. The PIN code length can
be a set number of 4, 5 or 6 digits or it can be a 4–8 digits option.
When choosing the 4- to 8-digit option, please note that you should
either enter zeros before the code, or press pound at the end (for
example, if your code is 12345, enter either 00012345 or 12345#).
Entering a code refers to either PIN or proximity card
depending on the model you have.
The way in which the two memory slots are programmed
determines a user’s access level and also determines the way in
which the unit grants access in its three modes of operation. There
are three user levels:
Normal
A Normal user only has a Primary code and is only granted
access when the unit is in Normal or Bypass mode.
