Auxiliary Mode 7
Auxiliary input function: Door Monitor
Auxiliary output activated by: Door Ajar (door held open)
E.g. In auxiliary mode 7, the controller can trigger the auxiliary
relay, if it detects that the door has been held open (ajar) too
long. In this mode the auxiliary input functions as a door monitor
switch and is wired to the magnetic contact switch on the door.
The auxiliary relay is to be wired to the alarm system. If the door is
opened, the controller will wait for the door ajar delay time to
elapse and if the door does not close prior to the end of this
period, the controller will activate the auxiliary relay. The auxiliary
setting defines the door-ajar time.
Auxiliary Mode 8
Auxiliary input function: Green LED control
Auxiliary output activated by: Valid user code, Auxiliary code
E.g. In auxiliary mode 8, the controller can function as a two-door
controller and also provide indicator functionality control. The
auxiliary relay is connected to the lock on the second door. The
auxiliary setting defines the door open time for the second door.
The auxiliary input is used to control the Door indicator. If the
auxiliary input is open, the indicator will flash green; if the auxiliary
input is closed, the Door indicator will flash red.
Note:
This mode takes control of the Door indicator LED.
The indicator LED will not be lit when:
A valid code is entered
While in secure mode, when waiting for a secondary code.
