General Information
AYC-Qx4 family manual Page 5
1.2 Reader/Controller Types
The different types of units described in this manual are:
• Type 54 has PIN only
• Type 64 has PIN and Proximity card
Backlight Keypad Type Proximity
AYC-Q54B
Standard
AYC-Q64B
Standard
Upon power-on reset, the AYC-Qx4 searches for the presence of
Rosslare's secure application appurtenances. If a secure
application appurtenance is detected, then the AYC-Qx4 is
automatically configured as a secure access control unit. This is
indicated by two short beeps. If the secured controller is not
detected, it is automatically configured as a reader, indicated by
one short beep.
1.3 Box Content
Before beginning verify that all of the following is in the box. If
anything is missing, please report the discrepancy to your nearest
Rosslare office.
• One AYC-Qx4 unit
• Installation kit
• Installation and operating instructions
• secure application appurtenance (optional for controller
applications)
