Controller Functionality
AYC-Qx4 family manual Page 32
Changing from Bypass Mode to Normal Mode
See Changing the Normal / Bypass Code and Door Chime
Settings on page 39 to create/modify the Normal / Bypass code.
1) Enter the 4 digit Normal /
Bypass code
• Mode LED will flash
green
2) Press the “#” key to
confirm the mode change.
• Mode LED will turn green
6.3 Auxiliary Input & Output
For optimum usability in different applications, the controller’s
auxiliary input and output can be configured in ten different
modes of operation.
6.4 Door Alarms
Door alarms can be generated by connecting the Auxiliary Input
to a Door Position Switch. Either Door-Forced or Door-Ajar
conditions are supported, as well as, a configurable delay timer
for each alarm type. Only one Door-alarm is enabled at any one
time. Door alarms may activate auxiliary output and siren
depending on the auxiliary settings.
Mode/Transmit
Door/Program
Green
Mode/Transmit
Door/Program
Green
Mode/Transmit
Door/Program
Oran
e
