Rotabroach ELEMENT 50 LOW PROFILE 1 - Page 13

Element 50 Low Profile Manual Original instructions 2019
13
Item#
Rotabroach P/N
Description
Qty/pcs
1
RDF2000
Spindle assembly
1
2
RDF4000
Screw
6
3
RDF4001
Circlip
2
4
RDF3000
Bearing bracket
1
5
RDF4002
Gear Shaft Washer
1
6
RDF4003
Circlip
1
7
RDF4004
Straight Pin
4
8
RDF2001
Slide assembly
1
9
RDF3001
Guard
1
10
RDF4005
Screw
6
11
RDF3002
Guide Bar
2
12
RDF4006
Screw
1
13
RDF2002/3
Magnet assembly 230v
1
RDF2002/1
Magnet assembly 110v
1
14
RDF4007
Screw
3
15
RDF4008
Screw
2
16
RDF4009
Screw
2
17
RDF3003
Capstan spindle
1
18
RDF4010
Circlip
6
19
RDF2003
Connected base assembly
1
20
RDF4011
Circlip
1
21
RDF4012
Screw
4
22
RDF2004
Gear Box assembly
1
23
RDF4013
Gear Shaft Washer
1
24
RDF2005
Shaft gear assembly
1
25
RDF3004
Handle
1
26
RDF4014
Straight Pin
1
27
RDF2006/3
Motor assembly 230v
1
RDF2006/1
Motor assembly 110v
1
28
RDF4015
Screw
4
29
RDF2007
Right cover shell subassembly
1
30
RDF4016
Screw
6
