Rotary 000 Series User Manual

60
Detail for PB-DS35/32-01
PartNo. Description Qty
1 B201-10*65 Hex socket head screw M10*65 4
2 B21-4*6 Hex socket set screw with at pointM4*6 2
3 B21-6*10 Hex socket set screw with at pointM6*10 14
4 B25-6*12 Hex socket pan head screw M6*12 8
5 B25-6*80 Hex socket pan head screw M6*80 4
6 XX140066 Sensor block 1
7 B30-6 Hex Nut M6 4
8 B30-10 Hex Nut M10 4
9 B41-24 Flat washer Φ24 4
10 B60-20 Circlip Φ20 4
11 B63-25 Circlip Φ25 8
12 K35-7010 Washer 12
15 XG130007 M20*1.0 slotted round locknut 12
16 XG130044 M6*10 set screw-cone point 8
17 XG130075 Proximity switch 2
18 XX110003 Ramp assembly 4
19 XX110006 Kicker assembly 2
20 XX120001 Platform weldment 2
21 XX120002 Base weldment 2
22 XX120003G Scissor leg weldment 1
23 XX120004G Scissor leg weldment 1
24 XX120005 Scissor leg weldment 1
25 XX120006 Scissor leg weldment 1
26 XX130080 Pin Long 2
27 XX130081 Pin long 4
28 XX130082 Lower cylinder pin 4
29 XX130086 Upper cylinder pin 2
30 XX130210 Cushion weldment 2
31 XX130214 Pin 2
32 XX130225 Stainless plate 2
33 XX130232 Cylinder cover 2
34 XX130233 Forming plate 2
35 XX140007
Slider block (Lower) 4
36 XX140008 Slider block (Upper) 4
37 XX140010 Cylinder 2
38 XX140011 Cylinder 2
39 XX140014Y Bearing 25dia*25 long 8
40 XX140015Y Bearing 25 dia*35 long 12
