Detail for XX110030G (DS35E,3ph 50/60HZ 230V/400)
PartNo. Description Qty
1 XX110016E 4 side open control cabniet (steel parts) 1
2 P3660 3Ph ,50/60HZ,230/400V 1
2.1 P1535 Tank 1
2.2 FA7146 3kw motor 1
2.3 P3000-24 Lowering valve with 24VDC solenoid 1
2.4 P1000-19 Relier Valve 1
2.5 P3665-1 Manifold with pump 1
3 To-2-1/EA/SVB(DQ-QJ-00034) Main switch 1
4 AD16-22/W23(DQ-QJ-00028) Light 1
5 CE4T-10R-01(DQ-QJ-00026) Emergency stop switch 1
6 DS35-DQ-ZP3 Lower to ground button 1
7 AD16-22SM/R Buzzer 1
8 DS35-DQ-ZP1G Up button 1
9 DS35-DQ-ZP2 Lower button 1
10 JBK5-230/380/400/AC18V Transformer 1
11 LS501 Fuse Block 3
12 RT18-25(220V) / RT18-16A(400V) 25A Fuse(220V) / 16A Fuse (400V) 3
13 DK10-TF Fuse Block 1
14 50CF-010F 1 A Fuse 1
15 PV-1030 Ground bar 1
16 DS35-DQ-PCB1A PCB Board 1
17 XTCG012B00B0 Contactor 1
18 BQ-021E Warning sticker 1
19 XG150085C Pipe(PVC) stud 4
20 B30-8 Hex NutM8 8
21 B40-8 Lock Washer Φ8 8
22 B41-8 Flat washer Φ8 8
23 PV-2005 Damping bolt 4
24 BQ-002 CE sticker 1
25 C30-BQ9 Decal 1
26 FKZJ-131A Addational manifold with solenoid 1
27 DS35D0-DQ4-2
EV1 Wire kit 1
28 DS35D0-DQ4-1 EV2 Wire kit 1
29 DS35D0-DQ4-3 Motor cable 4*1.5² 1
30 DS35EX-DQ4-4 Power cable 4*1.5² 1
31 DSS35-9801-8 Hydraulic hose 1
32 FJ7352-3 Fiiting on P1/P2 Port on Addational manifold 2
33 EPL8-02 Air tting(on the power unit tank) 1
34 EPY8 Y tting 1
35 Black Air tube 8mm(in parts box) 20m
* Note: Item 31/32/33/34/35 not show on the drawing.
