Detail for XX110019 (DS35N,1ph 50/60HZ 230V)
PartNo. Description Qty
1 AB302 Lock 1
2 AD16-22/W23(DQ-QJ-00028) Light 1
3 B23-4*16 Screw M4*16 7
4 B23-4*6 Screw M4*6 8
5/6/7 B30-8/B40-8/B41-8 Hex Nut M8/Lock Washer&Flat washe Φ8 8
8 CE4T-10R-01(DQ-QJ-00026) Emergency stop switch 1
9 DS35-DQ-ZP3 Lower to ground button 1
9.1 DS35-DQ-ZP2 Lower button 1
9.2 DS35-DQ-ZP1G Up button 1
10 AD16-22SM/R Buzzer 1
11 RGF2BU024L Relay 1
12 DS35-DQ-PCB1A PCB Board 1
13 JBK5-230/380/400/AC18V Transformer 1
14 P1-25/EA/SVB(DQ-QJ-00003) Main switch 1
15 P3669 Power unit 1
15.1 YBZ-SLYX-10L-L-A Tank 1
15.2 AM11-21IAM-3BA2R 3kw motor 1
15.3 LSV-08-2NCSP-LM-2H Solenoid valve 24VDC 1
LC3-10-C-2H Coil 1
15.4 LSV2-08-2NCP-J-2H Solenoid valve 24VDC 1
LC2-08-2H Coil 1
15.5 LPSRV2-08-50 Relier Valve 1
15.6 LBZ-T131KK-1 Manifold 1
15.7 CBKA-F2.5F Gear Pump 1
16 PV-1030 Grounding Bar 1
17 PV-2005 Damping bolt 4
18 XG150085C Pipe(PVC) stud 4
19 XX110016 Steel cabinet 1
20 C30-BQ9 Decal 2
21 LS501 Fuse Block 3
22 RT18-32 32A Fuse 3
23 FJ7352-3& M130028Y Fiiting on P1/P2 Port
2
24 EPL8-03 Air tting 1
25 EPY8 Y tting 1
26 Black Air tube 8mm(in parts box) 20m
27 DS35D0-DQ4-2 EV1 Wire kit 1
28 DS35D0-DQ4-1 EV2 Wire kit 1
29 DS35EX-1PH-DQ4-4 Power cable 3*2.5² 1
30 DS35N0-DQ4-3 Motor cable 3*2.5² 1
* Note: Item 23-30 not show on the drawing.
