Detail for XX110019G (DS35N,1ph 50/60HZ 230V)
PartNo. Description Qty
1 XX110016E 4 side open control cabniet (steel parts) 1
2 P3669 1Ph ,50/60HZ,230V power unit 1
2.1 YBZ-SLYX-10L-L-A Tank 1
2.2 AM11-21IAM-3BA2R 3kw motor 1
2.3 LSV-08-2NCSP-LM-2H Solenoid valve 24VDC 1
LC3-10-C-2H Coil 1
2.4 LSV2-08-2NCP-J-2H Solenoid valve 24VDC 1
LC2-08-2H Coil 1
2.5 LPSRV2-08-50 Relier Valve 1
2.6 LBZ-T131KK-1 Manifold 1
2.7 CBKA-F2.1F Gear Pump 1
3 P1-25/EA/SVB(DQ-QJ-00003) Main switch 1
4 AD16-22/W23(DQ-QJ-00028) Light 1
5 CE4T-10R-01(DQ-QJ-00026) Emergency stop switch 1
6 DS35-DQ-ZP3 Lower to ground button 1
7 AD16-22SM/R Buzzer 1
8 DS35-DQ-ZP1G Up button 1
9 DS35-DQ-ZP2 Lower button 1
10 JBK5-230/380/400/AC18V Transformer 1
11 LS501 Fuse Block 2
12 RT18-32 32A Fuse 2
13 RGF2BU024L Relay 1
14 PV-1030 Ground bar 1
15 DS35-DQ-PCB1A PCB Board 1
16 XG150085C Pipe(PVC) stud 4
17 BQ-021E Warning sticker 1
18 BQ-002 CE sticker 1
19 C30-BQ9 Decal 1
20 B30-8 Hex NutM8 8
21 B40-8 Lock Washer Φ8 8
22 B41-8 Flat washer Φ8 8
23 PV-2005 Damping bolt 4
24 DS35D0-DQ4-2 EV1 Wire kit 1
25 DS35D0-DQ4-1 EV2 Wire kit 1
26 FJ7352-3 & M130028Y Fiiting on P1/P2 Port 2
27 EPL8-03 Air tting 1
28 EPY8 Y tting 1
29 Black Air tube 8mm (in parts box) 20m
30 DS35EX-1PH-DQ4-4 Power cable 3*2.5² 1
31 DS35N0-DQ4-3 Motor cable 3*2.5² 1
* Note: Item 26/27/28/29 not show on the drawing.
