Detail for XX110021 (DS35D,3ph 50HZ 400V)
PartNo. Description Qty
1 AB302 Lock 1
2 AD16-22/W23(DQ-QJ-00028) Light 1
3 B23-4*16 Screw M4*16 7
4 B23-4*6 Screw M4*6 8
5/6/7 B30-8/B40-8/B41-8 Hex Nut M8/Lock Washer&Flat washe Φ8 8
8 CE4T-10R-01(DQ-QJ-00026) Emergency stop switch 1
9 DS35-DQ-ZP3 Lower to ground button 1
9.1 DS35-DQ-ZP2 Lower button 1
9.2 DS35-DQ-ZP1G Up button 1
10 AD16-22SM/R Buzzer 1
11 XTCG012B00B0 Contactor 1
12 DS35-DQ-PCB1A PCB Board 1
13 JBK5-230/380/400/AC18V Transformer 1
14 TO-2-1/EA/SVB (DQ-QJ-00034) Main switch 1
15 P3664 Power unit 1
15.1 YBZ-SLYX-10L-L-A Tank 1
15.2 AM63-4ILC-3BA1 3kw motor 1
15.3 LSV-08-2NCSP-LM Solenoid valve 24VDC 1
LC3-10-C-2H Coil 1
15.4 LSV2-08-2NCP-J Solenoid valve 24VDC 1
LC2-08-2H Coil 1
15.5 LPSRV2-08-50 Relier Valve 1
15.6 LBZ-T131KK-1 Manifold 1
15.7 CBKA-F2.5F Gear Pump 1
16 PV-1030 Grounding Bar 1
17 PV-2005 Damping bolt 4
18 XG150085C Pipe(PVC) stud 4
19 XX110016 Steel cabinet 1
20 C30-BQ9 Decal 2
21 LS501 Fuse Block 3
22 RT18-16 16A Fuse 3
23 DK10-TF Fuse Block
1
24 50CF-010F 1A Fuse 1
25 FJ7352-3& M130028Y Fiiting on P1/P2 Port 2
26 EPL8-03 Air tting 1
27 EPY8 Y tting 1
29 Black Air tube 8mm(in parts box) 20m
30 DS35D0-DQ4-2 EV1 Wire kit 1
31 DS35D0-DQ4-1 EV2 Wire kit 1
32 DS35EX-DQ4-4 Power cable 4*1.5² 1
33 DS35D0-DQ4-3 Motor cable 4*1.5² 1
* Note: Item 25-33 not show on the drawing.
