Rotary SPOA7 Installation Instruction

10
3 O 50/60 Hz.
MOTOR
1
3
5
1
2
3
4
7
5
8
6
9
L1
PE
L2
L3
L1
A2 A1
L2
L3
T1
T2
T3
N.O. N.O.
CONTROL BOX
OVERHEAD
LIMIT SWITCH
CONTACTOR
COIL
UP SWITCH
440-480V, 60Hz. 3Ø
400V, 480V 50Hz. 3Ø
3 O 50/60 Hz.
MOTOR
L1
PE
L2
L3
L1
A2 A1
L2
L3
1
3
5
1
7
2
8
3
9
4
5
6
T1
T2
T3
N.O. N.O.
208V, 220-240V
60Hz. 3Ø
CONTROL BOX
OVERHEAD
LIMIT SWITCH
CONTACTOR
COIL
UP SWITCH
LOW VOLTAGE CONNECTION
HIGH VOLTAGE CONNECTION
T1
T2
T3
T4
T5
T6
T7
T9
T8
L1
L2
L3
L1
L2
L3
T1 RED
T2 BLUE
T3 WHITE
T4 BLACK "R"
T5 BLACK "S"
L
E
G
E
N
D
T6 BLACK "T"
T7 BROWN
T8 YELLOW
T9 GREEN
T1 WHITE
T2 RED
T3 BROWN
T4 WHITE
T5 RED
L
E
G
E
N
D
T6 BLACK
T7 WHITE
T8 RED
T9 BLUE
Two different wiring colors were used. Determine appropriate LEGEND.
T1
T2
T3
T4
T5
T6
T7
T9
T8
Fig. 16
NOTES:
1. Unit not suitable for use in unusual conditions. Contact
Rotary for moisture and dust environment duty unit.
2. Control Box must be field mounted to power unit.
3. Requirements:
Use: FA7162 for 60 Hz. 208V Supply
FA7163 for 60 Hz. 220-240V Supply
FA7164 for 60 Hz. 440-480V or 50 Hz. 400V Supply
FA7165 for 50 Hz. 480V
4. *Verify Coil Rating Matches Supply Voltage
5. Motor rotation is counter clockwise from top of motor.
LINE VOLTAGE
208 - 230 Volts 60 HZ
460 Volts 60 HZ
MOTOR OPERATING DATA - THREE PHASE
197 - 253 Volts
414 - 506 Volts
RUNNING MOTOR VOLTAGE RANGE
Three Phase Rotary Power Unit

Rotary SPOA7 Specifications

General

Voltage	208-230V
Capacity	7000 lbs
Overall Width	132 inches
Load Capacity	7000 lbs
Power Source	Electric
Dimensions	132" W x 118" H
Weight	Unknown
