Effectivity: 447 UL SCDI, 503 UL DCDI, 582 UL DCDI /mod. 99
INSTALLATION MANUAL
AIRCRAFT ENGINES
page 11 - 5
Initial issue, May 01/99
d00321
1 crankcase 10 overflow hose
2 cylinder 11 overflow bottle
3 cylinder head 12 bottle venting
4 water pump 13 expansion tank
5 radiator 14 cylinder head venting hose
6 hose from radiator to the water pump 15 excess pressure valve
7 hose from cylinder head to the radiator 16 return valve
8 radiator screw cap, with excess
pressure valve and return valve
9 temperature gauge for cooling water
